Description
CZ-20 Curtain-Protected Laminar Flow Cabinet
CZ-20: ISO Class 5 Laminar Flow Cabinet with Protective Air Curtain Barrier.
Performance Table:
| Parameter | Specification | Compliance Advantage |
|---|---|---|
| Airflow Design | Vertical + Front Air Curtain | Enhanced personnel/product protection |
| HEPA Filtration | H14 Grade (EN 1822) | 99.995% @ 0.3μm efficiency |
| Air Velocity | 0.45 m/s (main) + 0.25 m/s (curtain) | ISO 14644-1 Class 5 |
| Work Area | 1200×600×900mm | Oversized processing zone |
| Noise Level | ≤63 dB(A) | 30% quieter than competitors |
| Material | SS304/316L options | Corrosion-resistant GMP compliance |
Dual-Protection Technology
Air Curtain System Benefits:
🛡️ Personnel Protection:
- Secondary airflow barrier reduces operator exposure
- Critical for cytotoxic drug preparation (USP <800>)
🛡️ Product Protection:
- Prevents ambient contamination during material transfer
- Maintains ISO 5 during door openings
🔬 Technical Innovation:
- Independently controlled curtain velocity (0.2-0.3 m/s)
- Low-turbulence edge design
Pharmaceutical Applications:
• Hazardous drug compounding (chemotherapy, hormones)
• Sterile API weighing & dispensing
• Vaccine research & cell culture work
• Medical device assembly
Competitive Advantages
Smart Operation Features:
📊 Integrated Monitoring:
- Real-time particle counter (0.3/0.5/5.0μm)
- Differential pressure display with alarm
💡 User-Centric Design:
- Sliding safety glass with one-hand operation
- Tool-less HEPA replacement (front access)
🌡️ Climate Adaptations:
- Humidity control package (SE Asia)
- Anti-static option (dry climates)
- Wide voltage input: 90-264V AC
Compliance Documentation:
✅ Validation Package Includes:
- Airflow visualization reports (smoke studies)
- HEPA certification (EN 1822:2019)
- Annex 1 IQ/OQ protocols
- Particulate mapping data
Technical Comparison
CZ-20 vs. Standard Laminar Cabinets:
| Feature | CZ-20 | Standard Cabinets |
|---|---|---|
| Contamination Protection | Dual barrier (vertical + curtain) | Single airflow |
| Door Opening Safety | <5% airflow disturbance | 35-55% disturbance |
| Noise Level | 63 dB | 68-72 dB |
| Filter Access | Front panel (5-min change) | Rear access (35+ min) |
| Compliance Docs | Full Annex 1 package | Basic certification |
CZ-20’s air curtain maintain ISO 5 during door opening: Particle counts remain stable while transferring materials.
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
Ready to Eliminate Production Bottlenecks?
Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
🌍 Regional Service Hubs: Dubai (MENA), Hanoi (SEA), Lagos (Africa).
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
⚙️ Rapid Customization: Customize equipment for unique products within 1-2 weeks.
🌐 Request Efficiency Audit: Free line analysis with 15% output improvement guarantee.
🛠️ On-Site Calibration: Available within 72hrs in key regions.
📊 Ramp-Up Assurance: On-site commissioning in <72hrs.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🌡️ For a free product compatibility test using your materials.
⚡Voltage customization available (110V-220V-380V-480V) — trusted by World industrial manufacturers in 16+ countries. Serving manufacturers in 12+ countries across Africa, SE Asia & MENA.
🛡️Support: EN/RU/AR/ES — On-site commissioning available globally.
📥Includes 24/7 remote monitoring and validation support (IQ/OQ/PQ).
✉️Multi-language HMIs, regional certifications included (International calls routed to English-speaking engineers).
Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
