Description

Sequential Front & Back Labeling for Premium Cylindrical Packaging

Precision Three-Roller Smoother and Dual-Reel Efficiency.

Ideal for Beverage, Pharma, Cosmetics & Chemical Industries.

This line addresses the specific need for applying two distinct labels—typically a primary front label and a secondary back label with legal or ingredient information—onto round containers in a single, automated process. It is particularly suited for premium products where presentation and information completeness are paramount, such as in the wine, spirits, and high-end cosmetic sectors.

Precision Three-Roller Smoother and Dual-Reel Efficiency

The LL-50 combines reliable mechanics with operational convenience:

• Dual-Reel (Dual-Spool) System: Equipped with two independent label reels, enabling long production runs without frequent reel changes and providing flexibility to use two different label types if needed.

• Three-Roller Label Smoother: A robust system comprising two pressure rollers and one main smoothing roller ensures the label is perfectly adhered around the entire bottle circumference without bubbles or wrinkles.

• Adjustable Performance: The smoother’s speed is controlled via a frequency converter and can be fine-tuned to match specific bottle dimensions for consistent, high-quality results.

• Enhanced Sensing: Standard optical sensor. An optional ultrasonic sensor is available for reliable application of clear or metallized labels.

• Alternative Smoother: The line can be optionally configured with an endless belt label smoother.

Ideal for Beverage, Pharmaceuticals, Cosmetics & Chemical Industries

Beverages and Alcohol: Ideal for labeling bottles of wine, champagne, spirits, and premium soft drinks (front and back labels).

Pharmaceuticals: Applying primary and secondary information labels to bottles.

Cosmetics and Personal Care: Labeling round bottles and jars with decorative and informational labels.

Chemical Industry: Labeling round containers of household and automotive chemicals where two labels are required.

Simple, Automated Operation with Quick Changeover

The workflow is designed for ease of use:

1. Loading: The operator places containers onto the conveyor.

2. Transport & First Application: The container passes the sensor, triggering the application of the first label (front label). It is smoothed by the roller system.

3. Second Application: After a precisely controlled interval, the container triggers the application of the second label (back label) from the second reel, which is also smoothed.

4. Discharge/Integration: The dual-labeled container exits. The system can include an indexing disc for spacing and connect to accumulation tables or downstream packaging equipment.

A Compact Solution for High-Quality Dual-Label Requirements

This configuration offers a space-efficient and highly efficient alternative to using two separate machines or manual processes for dual-label applications. Its compact footprint and dual-reel design make it an excellent choice for producers with limited space who require reliable, high-quality sequential labeling.

Built for Global Compliance and Supported Locally

Engineered for international markets with full regional support:

• Certifications & Standards: CE, EAC, ISO 9001. GMP-ready design with 316L Stainless Steel contact parts.

• Global Support Network: 24/7 multilingual support (EN/RU/AR/ES). Rapid on-site commissioning (<72 hours) and spare parts delivery from hubs in Dubai (MENA), Hanoi (SE Asia), and Lagos (Africa).

• Customization & Validation: Free product compatibility testing and line configuration. Voltage customization (110V-480V) is standard, backed by a 24-month performance guarantee.

Simple, Automated Operation with Quick Changeover.

A Compact Solution for High-Quality Dual-Label Requirements.
