Description

Precise, Mobile Labeling for Tall Bottles and Vials of Various Sizes

Core Components for Reliable, Adjustable Operation.

Simple, Automated Workflow for Consistent Results.

This mobile unit solves the challenge of labeling taller cylindrical containers that may not fit standard equipment. Designed for flexibility, it can be wheeled between production areas or dedicated to a specific line, providing labeling capabilities without permanent installation.

Core Components for Reliable, Adjustable Operation

The LL-50 is built around a robust set of core and optional modules:

• Mobile Frame: Floor-standing unit on casters for easy mobility.

• Belt Conveyor: Transports containers steadily through the labeling process.

• Labeling Head: Features a proprietary LOCUS-series side-mount applicator.

• Endless Belt Smoother: A superior alternative to multi-roller systems, this unit ensures bubble-free label application with speed adjustment via a frequency converter. It can be fine-tuned for different bottle diameters and heights.

• Sensing & Control: Optical sensor for reliable container detection and label triggering.

• Key Optional Upgrades: Ultrasonic sensor for applying clear labels, and a three-roller label smoother.

Technical Specifications & Integration Capabilities

Simple, Automated Workflow for Consistent Results

Operation is straightforward:

1. Loading: Operator places empty or capped bottles onto the conveyor.

2. Transport & Detection: Conveyor moves the bottle past the optical sensor.

3. Label Application & Smoothing: Sensor triggers the applicator to apply the label. The bottle then passes through the endless belt smoother, which perfectly adheres the label to the cylindrical surface.

4. Discharge: The labeled container exits, ready for packing or the next production step.

Modular Design for Stand-Alone or Inline Integration

The LL-50’s greatest strength is its versatility. It can function as a:

• Stand-Alone Labeling Station: For batch labeling operations.

• Integrated Line Component: Seamlessly connects with linear or rotary filling machines (piston, peristaltic, gear pump types) and automatic cappers to form a complete filling-capping-labeling monobloc or tribloc system.

Built for Compliance and Supported Globally

Engineered for international deployment with a focus on your operational success:

• Certifications & Standards: CE, EAC, ISO 9001. GMP-ready design with 316L SS contact parts and cleanability.

• Global Support Network: 24/7 multilingual support (EN/RU/AR/ES). Rapid on-site commissioning (<72 hours) and spare parts delivery from hubs in Dubai (MENA), Hanoi (SE Asia), and Lagos (Africa).

• Customization & Validation: Free product compatibility testing and line configuration analysis. Voltage customization (110V-480V) is standard, backed by a 24-month performance guarantee.

Modular Design for Stand-Alone or Inline Integration.

Built for Compliance and Supported Globally.
