Fully Automatic Cartridge Filling and Capping Monoblock for Industrial Chemicals

TBC-30 Automatic Rotary Tube Filling Machine for Construction. Chemicals.

Fully automatic rotary cartridge packaging monoblock.

Automatic cartridge orientation and filling system.

High-Speed Packaging Solution for Construction Chemicals
The TBC-30 automatic rotary monoblock represents the pinnacle of efficiency for packaging viscous construction chemicals and industrial compounds. Its rotating disc design with multiple workstations allows simultaneous operations, significantly increasing throughput while maintaining exceptional accuracy. Specifically engineered to handle challenging materials including polyurethane sealants, construction adhesives, industrial lubricants, and various technical chemicals.

Key Features:

• ✅ Rotary Indexing Table: Enables continuous high-speed operation with multiple stations

• ✅ Automatic Tube Orienter: Ensures precise positioning for error-free operation

• ✅ High-Speed Production: 30+ tubes per minute capacity

• ✅ Chemical-Resistant Construction: SS304/316 stainless steel contact parts

• ✅ Precision Filling: ±1% volume accuracy with servo-driven pumps

Advanced Technical Features

• Rotary Indexing System: 6-station rotating table enables continuous processing without interruption

• Automatic Tube Orientation: Precision mechanical orienters ensure perfect tube positioning

• Servo-Driven Filling System: Programmable logic control with touchscreen interface for exact volume dosing

• Heavy-Duty Construction: Full SS316 stainless steel contact parts resist corrosive chemicals

• Quick Changeover: Tool-less adjustment for different tube sizes and formats

• Integrated Safety Features: Emergency stops, safety guards, and overload protection

This fully automatic rotary-type monoblock represents a complete packaging solution for industrial chemicals and sealants in cartridge format. The integrated system features automatic cartridge orientation, precision filling with multiple nozzles, hydraulic compression system, cap orientation, and automatic capping functionality. With a production capacity exceeding 1000 cartridges per hour, this high-speed system is ideal for packaging technical lubricants, construction adhesives, sealants, and various industrial chemical compounds.

Key Features:

• Complete automated packaging process

• Automatic cartridge orientation and feeding

• Multiple filling nozzles for high-speed operation

• Hydraulic compression system for viscous products

• Automatic cap orientation and capping

• Production capacity: 1000+ cartridges/hour

• SS304/316 stainless steel construction

• PLC control with touchscreen interface

High-Speed Automated Packaging Solution
This fully automatic rotary monoblock integrates all packaging stages into a single, efficient system. The machine’s rotary design enables continuous operation with multiple simultaneous processes, maximizing productivity while maintaining consistent quality for industrial chemical packaging.

Technical Specifications Table:

Key Benefits:

• High Efficiency: Rotary design enables continuous production with minimal downtime

• Precision Packaging: Multiple filling nozzles ensure accurate dosing and consistent quality

• Automated Process: Complete automation from empty cartridge feeding to capped product

• Versatile Application: Handles various viscous industrial products

• Robust Construction: Stainless steel components withstand harsh chemical environments

• Easy Operation: User-friendly interface with recipe storage and quick changeover

Industries Served:

• Construction chemicals manufacturing

• Industrial lubricant production

• Sealant and adhesive manufacturing

• Technical chemical packaging

• Automotive product packaging

Applications & Industries

• Construction Chemicals: Sealants, adhesives, caulks, mortars

• Industrial Lubricants: Greases, lubricating compounds

• Technical Chemicals: Specialty compounds, maintenance products

• Building Materials: Construction adhesives, repair compounds

Why Choose TBC-30 Rotary Monoblock?

• Increased Productivity: Rotary design enables 30% higher output vs linear machines

• Superior Accuracy: Servo-controlled dosing ensures consistent fill volumes

• Reduced Labor: Fully automatic operation minimizes manual intervention

• Easy Maintenance: Quick-disconnect components and accessible design

• Global Compliance: CE certification and international safety standards

Hydraulic compression system for viscous chemicals.

Industrial chemical packaging production line.

TBC-30 Automatic Rotary Monoblock with Tube Orienter.
