Description
Compact Robotic Case Sealer for Cardboard Pharm Boxes
Robotic arm sealing food export box.
H-style tape pattern on FEFCO 0427 case.
Teach pendant programming interface.
Core Technology
-
Robotic Sealing Arm: KUKA KR 6 R700 six-axis robot (1,500mm reach) applies tape/hot-melt with ±0.1mm repeatability.
-
Multi-Sealing Modes: Handles H-style, I-style, and full-wrap patterns with 48-72mm tape or EVA adhesive.
-
Vision-Guided Adjustment: Laser sensors detect box dimensions (150-800mm L × 100-600mm W × 80-500mm H), auto-calibrating seal paths.
-
Tropical Resilience: Operates at 45°C/85% humidity (critical for SEA/Africa) with dust-proof servo motors.
Performance Specifications
| Parameter | Value |
|---|---|
| Throughput | 10-35 boxes/min |
| Box Types | FEFCO 0201 (RSC), 0427 (auto-bottom), 0404 (telescopic) |
| Sealing Pressure | 8-12 kg/cm² (adjustable) |
| Power | 7.5 kW (220V/380V) |
| Compressed Air | 0.6 MPa @ 200 L/min |
Industry Applications
-
E-commerce: Seals Amazon FBA, Walmart, and Alibaba-standard boxes with <0.5% error rate.
-
Pharma: GMP-compliant sealing for sterile kit packaging (ISO 15378 certified).
-
Food Export: Withstands -25°C to +65°C; compatible with wax-coated produce boxes.
-
Automotive: Seals heavy-duty parts cases (up to 50kg load).
Workflow Integration
-
Box Infeed: Automatic conveyor indexing.
-
Robotic Sealing: 6-axis arm applies tape/glue to top/bottom seams.
-
Quality Check: Vision system inspects seal integrity.
-
Outfeed: Direct to palletizer or packing station.
Format change: <4 mins via teach pendant
Competitive Advantages
| Feature | Benefit |
|---|---|
| Dual Sealing Options | Tape (pressure-sensitive) or hot-melt glue for wet/cold environments |
| Plug-and-Play PLC | Siemens S7-1200 integration with WMS/ERP systems (OPC UA protocol) |
| Energy Recovery | Regenerative drives cut power use by 35% vs. conventional sealers |
| Sanitary Design | IP65 rating; 316L stainless steel; no lubricant contact zones |
Regional Adaptation
-
Middle East/Africa: Sand-resistant components; 45°C operating limit.
-
SEA/Latin America: 220V/50Hz support; multi-language interface (EN/ES/ID).
-
Eastern Europe: GOST-certified electricals; local service in Serbia/Romania.
Compliance & Certifications
-
Robotics: ISO 10218-1 (Safety).
-
Sealing: FDA 21 CFR 175.105 (indirect food contact).
-
Electrical: CE, UL, GOST-R.
-
Pharma: ISO 15378 (Primary packaging materials).
Technical Support
-
Remote diagnostics via VPN.
-
Spare parts guaranteed 10+ years.
-
Training simulators in English/Spanish/Arabic.
