Description
The LRBM-500 represents advanced technology in PET bottle manufacturing, combining high production capacity with precision engineering. This fully automatic blowing machine features an integrated preform orienter and elevator system that ensures smooth and continuous operation, minimizing downtime and maximizing output efficiency.
Technical Excellence:
-
High Production Capacity: Up to 4000 bottles per hour depending on bottle size and design
-
Integrated Preform Handling: Automatic orienter and elevator system for continuous operation
-
Energy Efficiency: Advanced heating system with precise temperature control reduces energy consumption
-
Precision Molding: Consistent wall thickness and excellent bottle quality
-
Quick Mold Change: Hydraulic system allows for rapid mold changes and format adjustments
-
Quality Control: Integrated vision inspection system ensures product quality
-
Hygienic Design: Stainless steel construction meets food-grade requirements
Production Process:
-
Preforms automatically fed via elevator system
-
Precision infrared heating for optimal material distribution
-
High-pressure blowing with stretch rod technology
-
Precision molding with temperature-controlled molds
-
Automatic bottle ejection and quality inspection
-
Output to conveyor system for downstream packaging
Technical Specifications:
| Parameter | Specification |
|---|---|
| Model | LRBM-500 |
| Production Capacity | Up to 4000 bottles/hour |
| Max. Bottle Volume | 5000 ml |
| Preform Size Range | 10-150 g |
| Number of Cavities | 10-20 (depending on bottle size) |
| Power Requirements | 380V/50Hz, 85 kW |
| Air Consumption | 1.2 MPa, 12 m³/min |
| Machine Dimensions | 6000 × 2500 × 3500 mm |
| Control System | Siemens PLC with 15″ touch screen HMI |
| Energy Consumption | ≤ 0.35 kWh/kg |
Applications:
-
Beverage Industry: Water bottles, soft drink containers, juice bottles
-
Food Packaging: Edible oil bottles, sauce containers, food-grade packaging
-
Cosmetics: Shampoo bottles, lotion containers, cosmetic packaging
-
Pharmaceutical: Medicine bottles, healthcare product containers
-
Household Chemicals: Detergent bottles, cleaning product containers
Regional Adaptation:
-
Southeast Asia: energy efficiency and humidity resistance
-
European Markets: CE compliance and energy-saving features
-
North America: FDA compliance and production efficiency
-
Middle East: high-temperature operation and reliability
Competitive Advantages:
-
30% higher energy efficiency compared to conventional machines
-
Integrated preform handling reduces labor requirements
-
Quick mold change system minimizes downtime
-
Advanced heating system ensures consistent quality
-
Robust construction for 24/7 operation
-
Low maintenance requirements
Why Choose LRBM-500?
-
High Production Capacity: Maximize output with 4000 bottles/hour
-
Excellent ROI: Energy-efficient operation reduces operating costs
-
Quality Assurance: Consistent bottle quality with precise wall thickness control
-
Flexible Production: Quick changeover between different bottle designs
-
Reliable Performance: Designed for continuous operation with minimal maintenance
-
Global Standards: Complies with international safety and quality standards
