Description

Precision, Elegance, and Speed for Luxury Fragrance Packaging

The LR-20 Automatic Filling and Capping Monoblock represents the pinnacle of packaging technology for the luxury fragrance and fine cosmetics industry. This machine is not merely equipment; it is a guarantee of consistency, elegance, and preservation of your scent's integrity from production line to consumer.

Precision Engineered for Perfume Excellence

Fragrances are high-value, often volatile products where every drop counts. The LR-20 addresses this with its selection of ultra-precise vacuum or piston dosing systems. The vacuum dosing method is exceptionally gentle, ideal for avoiding aeration and preserving the top notes of delicate perfumes. Our alternative piston fillers provide robust, high-accuracy volumetric filling for a wider range of viscosities. Both systems are equipped with dual-component (two-stage) nozzles that fill by level, ensuring each bottle is filled to the exact same height—a critical visual standard for luxury goods—regardless of minor bottle volume inconsistencies.

The Art of Secure Capping: Multi-Leaf Collet Head

The second stage of the LR-20 monoblock features an advanced multi-leaf collet capping head. This mechanism is specifically designed to handle smooth, aluminum spray pump caps (also known as perfume stem caps) without marring their flawless finish. The collet gently but firmly grips the cap and applies a consistent, programmable crimping force to the bottle neck, creating a perfect, tamper-evident, and leak-proof seal. This process ensures the fragrance remains pure and the actuator functions flawlessly every time.

Key Features & Technical Advantages:

• Monoblock Design: Integrates filling and capping into one compact unit, saving floor space, reducing product transfer, and enhancing hygiene.

• Quick Changeover: Tool-less adjustments allow for rapid switchovers between different bottle shapes (cylindrical, oval, sculpted) and cap sizes, maximizing production flexibility for small and medium batches.

• Hygienic & GMP-Compliant Construction: Built with 304 or 316L stainless steel on all product contact surfaces. Features rounded corners, easy-access panels, and a design philosophy that meets stringent cosmetic (ISO 22716) and pharmaceutical-grade hygiene standards.

• User-Friendly Control: Intuitive PLC with touchscreen HMI allows for recipe storage, parameter adjustment, and production monitoring. Diagnostics are clear and accessible.

• Gentle Handling: Customizable conveyor guides and grippers ensure even the most delicate crystal glass bottles are transported safely through the process.

Compatible Products & Containers:

• Products: Premium perfumes (Parfum), Eau de Parfum (EDP), Eau de Toilette (EDT), fragrance oils, concentrated cosmetic serums, and other high-value liquids.

• Containers: Glass flacons (crystal, standard glass), luxury plastic (PET, acrylic) bottles in various shapes and sizes.

• Closures: Smooth aluminum spray pump caps (stem caps), other crimp-style luxury closures.

Why Choose the LR-20 for Your Fragrance Line?

For brands in Southeast Asia, the Middle East, Africa, Latin America, and Eastern Europe, the LR-20 offers a perfect balance of European-level precision and practical durability. It delivers the impeccable quality required by global luxury markets while being built for reliable performance and supported by accessible technical service. Protect your brand’s reputation with packaging as flawless as your fragrance.
