Description
LSSC-100 forming FMCG export boxes
Pressure-sensitive tape application on box bottom.
HMI interface with box dimension presets.
Key Features
-
Integrated Sealing System: Applies 48-72mm pressure-sensitive tape (water-activated tape optional) with 12kg/cm² pressure.
-
Rapid Conversion: Change box sizes in <5 mins via HMI interface (supports 150-600L x 100-400W x 80-400H mm).
-
Precision Folding: Servo-guided arms ensure <0.5° angle deviation on critical glue flaps.
-
Material Flexibility: Handles B/C/E-flute corrugated (200-500 GSM), including wax-coated produce boxes.
Performance Specifications
| Parameter | Value |
|---|---|
| Throughput | 10-30 boxes/min (900-1,500/hr) |
| Box Dimensions | L: 150-600mm, W: 100-400mm, H: 80-400mm |
| Tape Width | 48-72mm (standard) |
| Power Consumption | 2.2 kW (220V) — 3.8 kW (380V) |
| Air Supply | 0.6 MPa @ 120 L/min |
Industry Applications
-
Agriculture: Produce boxes with ventilation slots (tomatoes, berries).
-
Pharma: Sterile RSC cases for vial packaging (GMP-compliant design).
-
E-commerce: Automated fulfillment center integration via PLC (Siemens/Allen-Bradley).
Workflow Process
-
Blank Feeding: Automatic suction cup pickup.
-
Box Formation: Rotary arms fold side walls.
-
Bottom Sealing: Tape applied to center seam + side flaps.
-
Output: Conveyed to filling line (gravity roller compatible).
Operational noise: <72 dB | Requires 1 operator for tape reel changes
Technical Advantages
-
Zero Rejects: Laser-guided flap detection ensures 99.94% seal integrity.
-
Tropical-Ready: Seals reliably at 85% humidity (critical for SEA/Latin America).
-
Sanitary Design: 304 stainless contact points, IP54 rating for washdown environments.
-
Energy Saving: 35% lower consumption vs. pneumatic competitors.
Regional Optimization
-
Middle East/Africa: Highlight dust-resistant servos and 45°C operating limit.
-
SEA: Emphasize compatibility with humid environments and tropical corrugated grades.
-
Eastern Europe: Reference GOST 7376-89 cardboard standards and 220V/50Hz support.
Compliance & Standards
-
Mechanical: CE, ISO 13849-1 (Safety).
-
Materials: FDA 21 CFR 176.170 (Indirect food contact).
-
Design: FEFCO 0201, ECMA Code 50.
📜 Schedule virtual airflow visualization test.
💡 Mention your: Target market (EU/US/Global South), Active ingredient, Required throughput.
🔬 Schedule virtual factory acceptance test with our engineers.
🏷️ Request Compliance Audit: Free gap analysis with throughput simulation.
Ready to Eliminate Production Bottlenecks?
Need Industrial Production Automation?
✅ GMP Compliance Guarantee
✅ 24/7 Multilingual Support
✅ 24-month performance guarantee
✅ Local technicians in 18 countries
Start small, get a free production layout designed for your growth trajectory. Scale smarter with engineering support!
📥Free line configuration for your products, throughput validation testing!
🎓Contact Specialists for Packaging Equipment:
📄 On-Demand Engineering: Product-specific configurations in 1-2 weeks.
🔧 Spare Parts Kits: Region-specific inventory for <24hr delivery.
🌡️ For a free product compatibility test using your materials.
Compliance Roadmap:
- CE, EAC, ISO 9001 certifications.
- GMP-ready: 316L SS contact parts, CIP/SIP capabilities.
- ATEX options for chemical solvents.
