Automatic Linear-Type Cartridge Filling and Capping Monoblock

TBC-30 Semi-Automatic Cartridge Packaging Monoblock.

Automatic linear cartridge filling machine for construction chemicals.

Cartridge orientation and capping system.

This automatic linear-type monoblock is specifically engineered for packaging construction chemicals and industrial compounds into cartridges. The system features automatic cartridge orientation, precision filling with single nozzle dispenser, cap orientation, and automatic capping functionality. With optional hydraulic press integration, this machine efficiently handles viscous products including sealants, construction adhesives, industrial lubricants, and various technical chemicals. The robust construction ensures reliable performance in demanding industrial environments.

Key Features:

• ✅ Automatic Cartridge Orienter: Ensures correct positioning for error-free operation.

• ✅ Servo-Driven Piston Dispenser: Provides precise filling volumes with ±1% accuracy.

• ✅ High-Speed Operation: Capable of up to 30 cartridges per minute.

• ✅ Hygienic Design: SS304/316 stainless steel construction, compliant with GMP standards.

• ✅ User-Friendly Interface: Easy-to-use controls for quick changeover and minimal downtime.

Precision Filling for Industrial Cartridge Packaging
The TBC-30 semi-automatic monoblock combines advanced servo-driven technology with an automatic cartridge orienter to deliver reliable and accurate packaging for viscous industrial products. Designed for sealants, lubricants, construction chemicals, and technical compounds, this system ensures consistent results with minimal operator intervention. Its robust construction and precision components make it suitable for demanding industrial environments across various sectors .

Advanced Features for Enhanced Performance

• Automatic Cartridge Orienter: Guarantees correct positioning of cartridges before filling, reducing errors and maximizing efficiency.

• Servo-Driven Piston Dispenser: Offers precise volumetric control with ±1% accuracy, minimizing product waste and ensuring consistency.

• High-Speed Operation: Achieves speeds of up to 30 cartridges per minute, ideal for small to medium-scale production.

• Hygienic Construction: Made from SS304/316 stainless steel, meeting industry standards for cleanliness and durability.

• User-Friendly Controls: Simplified interface allows for easy operation and quick changeover between different cartridge sizes and products.

Key Features:

• Automatic cartridge orientation system

• Precision single-nozzle filling system

• Automatic cap orientation and capping

• Optional hydraulic press integration

• Handles high-viscosity products

• SS304/316 stainless steel construction

• PLC control system with touch interface

• Easy changeover between container sizes

Technical Specifications:

Advanced Packaging Solution for Industrial Chemicals
This linear automatic monoblock provides complete packaging solution for construction chemicals and industrial compounds. The machine’s robust design ensures reliable operation with high-viscosity products while maintaining precision and efficiency.

Technical Specifications Table:

Key Benefits:

• Efficient Operation: Automatic orientation systems minimize manual handling

• Precision Filling: Single nozzle dispenser ensures accurate volume control

• Versatile Application: Handles various construction chemicals and lubricants

• Robust Construction: Stainless steel components withstand harsh chemicals

• Flexible Configuration: Optional hydraulic press for different product types

Industries Served:

• Construction chemicals manufacturing

• Industrial lubricant production

• Sealant and adhesive manufacturing

• Technical chemical packaging

Why Choose the TBC-30 Semi-Automatic Monoblock?

• Precision and Consistency: Servo-driven technology ensures accurate filling volumes, reducing waste and enhancing product quality.

• Ease of Use: Automatic cartridge orienter and user-friendly controls minimize training requirements and operator error.

• Versatility: Suitable for a wide range of products and cartridge types, from sealants to lubricants.

• Durability: Robust construction designed to withstand harsh industrial environments with minimal maintenance.

• Global Compliance: Built to perform reliably in diverse climates and markets, including Southeast Asia, Africa, and Latin America.

Industrial chemical packaging monoblock.

Linear packaging system with hydraulic press.

TBC-30 Semi-Automatic Cartridge Filling Monoblock with Automatic Orienter.
