Description

🍸 Comprehensive Overview of RC-100 Vodka and Spirits Bottling Monoblock with Aluminum Screw Cap Sealing

RC-100 monoblock is a specialized rotary system designed for rinsing, filling, and capping vodka and spirit-based products using aluminum screw caps.

⚙️ 1. Technical Specifications and Design

• Capacity: The machine can handle up to 400 bottles per hour for semi-automatic operations (higher capacities available for industrial-scale production).

• Bottle Compatibility: Primarily designed for glass bottles (diameter: ø55–115 mm; height: up to 370 mm) but adaptable to PET bottles and other containers with specific accessories.

• Filling Technology: Uses isobaric (counter-pressure) filling to prevent oxidation and preserve product quality. The system includes a tank with a working pressure of up to 5 bar and options for oxygen pre-evacuation.

• Capping System: Equipped with a turret for applying aluminum screw caps, ensuring secure sealing. The closing head is made of hardened steel for durability.

• Construction: Built from stainless steel and food-grade materials compliant with international regulations (e.g., EC 1935/2004 for food contact materials).

• Power Requirements: Operates on 220V 50Hz single-phase power (other voltages available on request), with low energy consumption (installed power: ~1.1 kW).

🔄 2. Key Features and Process

• Integrated Operations: Performs rinsing, filling, and capping in a single unit, reducing contamination risks and saving floor space.

• Rinsing Module: Uses water or sterile air to clean bottles before filling, ensuring hygiene.

• Precision Filling: The isobaric system minimizes oxygen exposure by injecting CO₂ to create a neutral atmosphere, crucial for preserving the clarity and taste of vodka and spirits.

• Cap Application: Includes an automatic cap orienter and feeder (e.g., vibration hopper) to ensure consistent cap placement.

• Hygiene and Maintenance: Designed for easy cleaning with CIP (Clean-in-Place) capabilities and accessible components.

• Advanced Controls: Features a PLC with touchscreen interface for adjusting parameters (e.g., filling volume, capping torque) and storing recipes. Optional remote monitoring for Industry 4.0 integration.

Technical Specifications:

• Safety Certification: ATEX/IECEx Explosion-Proof Rating (Zone 1/21, Zone 2/22)

• Product Compatibility:

  • Vodka and neutral spirits

  • Brandy, cognac, and distilled beverages

  • Flammable alcohol solutions (LVZh)

  • Spirit-based products containing >20% alcohol

• Rinsing Options: Water or alcohol rinsing (ethanol compatible)

• Cap System: Aluminum screw caps with thread-rolling technology

• Production Capacity: 3,000-4,000 bottles/hour

• Construction: 316L stainless steel, explosion-proof components

• Safety Features: Intrinsic safety (Ex i), flameproof enclosures (Ex d)

Technical Advantages:

• Explosion Protection: ATEX-certified for safe operation in explosive atmospheres

• Alcohol Resistance: Compatible with high-proof spirits and rinsing agents

• Precision Filling: Volumetric dosing accuracy ±0.5%

• Thread Rolling Technology: Secure seal formation on aluminum caps

• Flexible Rinsing: Water or alcohol rinsing options

• High-Speed Operation: Efficient production capacity

• Safety Compliance: Meets explosive atmosphere regulations

Safety Features:

• Explosion-Proof Motors: Certified for hazardous areas

• Intrinsic Safety Barriers: Electrical system protection

• Vapor Extraction: Optional fume management system

• Emergency Stops: Quick shutdown capability

• Grounding System: Static electricity protection

• Safety Guarding: Full protection for operators

Special Components:

• Alcohol Rinsing Module: Water or spirit rinsing capability

• Precision Dosing System: Rotary filler for accurate volumes

• Elevator Cap Orienter: Handles vodka-style aluminum closures

• Thread-Rolling Capper: Forms threads on aluminum caps

• Explosion-Proof Controls: Certified electrical components

• Grade Materials: Alcohol-resistant construction

Applications:

• Vodka Distilleries: Premium vodka packaging

• Brandy Houses: Cognac and brandy bottling

• Spirit Producers: Whiskey, rum, and specialty spirits

• Flammable Liquids: Other LVZh packaging applications

Quality Features:

• Consistent Filling: Maintains precise alcohol content

• Secure Sealing: Tamper-evident thread formation

• Product Protection: Prevents contamination and evaporation

• Visual Appeal: Professional packaging presentation

• Regulatory Compliance: Meets alcohol industry standards

Operation Benefits:

• Safety Assurance: Certified for explosive environments

• Production Efficiency: High-speed operation

• Product Quality: Maintains spirit characteristics

• Flexibility: Handles various spirits and bottles

• Reliability: Consistent performance with valuable products

• Compliance: Meets international safety standards

🍶 3. Applications and Use Cases

• Vodka and Spirits: Ideal for vodka, whiskey, gin, and other spirits requiring precise filling and secure sealing.

• Product Types: Handles still liquids, fruit-infused spirits, and viscous products (e.g., fruit-based vodkas).

• Winery and Distillery Size: Suitable for small to medium-sized operations (semi-automatic mode) but scalable for larger productions with higher-capacity models.

💎 4. Advantages and Compliance

• Quality Assurance: Ensures consistent fill levels and secure capping, reducing waste and maintaining product integrity.

• Flexibility: Adaptable to various bottle sizes and closure types (e.g., aluminum screw caps, cork stoppers) with quick changeover.

• Safety and Compliance: Meets Machinery Directive 2006/42/EC and other international standards. Includes safety guards and emergency stop systems.

• Cost-Effectiveness: Low operational costs due to automated processes and minimal manual intervention..

📦 5. Optional Accessories and Customization

• Oxygen Evacuation Systems: Pre- or double pre-evacuation to further reduce oxygen exposure.

• Neck Handling Devices: For PET bottles or non-glass containers.

• CO₂ Injection: For carbonated spirits or products requiring additional preservation.

• Customizable Controls: UL/CSA-compliant electrical systems for U.S. and Canadian markets
