Description

Complete Solution for Pharmaceutical Ampoule Packaging

The A-50 Automatic Monoblock represents the pinnacle of efficiency in pharmaceutical ampoule processing. This integrated system handles the entire packaging process from empty ampoule feeding to final sealed product, eliminating transfer points and minimizing contamination risk. The machine’s robust construction and precision engineering make it ideal for demanding production environments requiring strict adherence to GMP standards.

Key Features/Benefits

• Integrated Monoblock Design: Combines precision filling and hermetic sealing in a single automated unit for streamlined production

• High-Speed Operation: Optimized for maximum throughput with production rates up to [X] ampoules per minute

• Multiple Dosing Options: Available with piston dispensers, peristaltic pumps, or ceramic pumps for different product viscosities

• Nitrogen Purging System: Optional inert gas injection protects oxygen-sensitive products from degradation

• GMP-Compliant Construction: Full stainless steel (AISI 304/316L) contact parts with cleanline design

Technical Specifications

• Machine Type: Automatic ampoule filling and sealing monoblock

• Production Capacity: 50-150 ampoules/minute (configurable)

• Ampoule Size Range: 1-20 ml glass ampoules

• Filling Accuracy: ±0.5% to ±1% (product dependent)

• Sealing Method: Oxygen-propane gas burners

• Power Requirements: 380V/220V, 50/60Hz

• Compressed Air: 0.6-0.8 MPa, 0.5 m³/min

Advanced Control & Monitoring

• PLC with touchscreen HMI for intuitive operation

• Recipe storage for quick product changeover

• Real-time monitoring of production parameters

• Data logging for batch traceability

• «No ampoule — no fill» detection system

Applications & Industries

• Pharmaceutical: Injectables, vaccines, antibiotics, hormones

• Biotechnology: Biological samples, research reagents

• Veterinary: Animal health products

• Cosmetic: Ampoule-based skincare products

Technical Advantages

• Quick Changeover: Tool-free adjustments for different ampoule sizes

• Minimal Maintenance: Robust construction with easy-access service points

• Energy Efficient: Optimized gas consumption for sealing

• Operator Safety: Integrated safety guards and emergency stop systems

• Validation Support: Documentation package facilitates regulatory approval
